Inductive

M18 Analog Inductive Proximity Sensor – 0–10 V Output, Sn: 8 mm

Non-contact detection of metal targets for machine positioning and part presence.

8 mm
Sensing range
0–10 V
Output
Cable
Connection
M18
Housing
15- 35 VDC
Supply
Non-flush
Mounting
PRODUCT SPECIFICATIONS

Technical data

M18 Analog Proximity Switch 0-10 VDC Output Sn : 0-8 mm Catalog reference
Technical specifications for M18 Analog Proximity Switch 0-10 VDC Output Sn : 0-8 mm
Sensing01
TechnologyInductive
ManufacturerDolphin
Housing / formM18
Sensing range8 mm
Electrical02
Operating voltage15- 35 VDC
Output circuit0–10 V
Switching functionTo be confirmed
Maximum load currentTo be confirmed
Mechanical03
ConnectionCable
Wire count3
Wiring notesTo be confirmed
Cable length2 m
MountingNon-flush
Housing materialMetallic Nickel plated
Dimensions / length70 mm
Dimensional reference04
Body diameter18 mm
Housing length (excluding tip)70 mm
Data source & verification

Based on Dolphin’s supplied product information. Confirm the exact orderable configuration with the team.

DOCUMENTATION

Downloads

Manufacturer documentation is not attached. Request the exact wiring and dimensional reference before installation.
