Magnetic
CYL Pneumatic cylinder
2-wire

To be confirmedCable
Magnetic cylinder-position sensor. Detects the piston magnet at a selected position; confirm the mounting profile and electrical configuration for your cylinder.
| Sensing01 | |
|---|---|
| Technology | Pneumatic cylinder |
| Manufacturer | Dolphin |
| Housing / form | CYL |
| Sensing range | To be confirmed |
| Electrical02 | |
| Operating voltage | 5~240V AC/DC Both |
| Output circuit | 2-wire |
| Switching function | To be confirmed |
| Maximum load current | 100mA |
| Mechanical03 | |
| Connection | Cable |
| Wire count | 2 |
| Wiring notes | To be confirmed |
| Cable length | 2 m |
| Mounting | To be confirmed |
| Housing material | PVC |
| Dimensions / length | To be confirmed |
| Magnetic detection04 | |
| Status indicator | Red LED |
| Installation | Pneumatic cylinder; confirm profile and mounting compatibility. |
Based on Dolphin’s supplied product information. Confirm the exact orderable configuration with the team.
Manufacturer documentation is not attached. Request the exact wiring and dimensional reference before installation.
Start with your target and installation to compare suitable configurations.
