Pneumatic cylinder

Pneumatic Magnetic Sensor

Magnetic Sensors

Magnetic cylinder-position sensor. Detects the piston magnet at a selected position; confirm the mounting profile and electrical configuration for your cylinder.

To be confirmed
Sensing range: 2-wire
Output: Cable
Connection: CYL
Housing: 5~240V AC/DC Both
Supply: To confirm
Mounting

PRODUCT SPECIFICATIONS

Technical data

Download CSV

Pneumatic Magnetic Sensor Catalog reference

Technical specifications for Pneumatic Magnetic Sensor
Sensing01
Technology	Pneumatic cylinder
Manufacturer	Dolphin
Housing / form	CYL
Sensing range	To be confirmed
Electrical02
Operating voltage	5~240V AC/DC Both
Output circuit	2-wire
Switching function	To be confirmed
Maximum load current	100mA
Mechanical03
Connection	Cable
Wire count	2
Wiring notes	Catalogue audit 25 October 2026: 2 conductors recorded from explicit, consistent product notation (). Source-based catalogue value; wiring diagram and terminal assignment still require verification.
Cable length	1.5 METER
Mounting	To be confirmed
Housing material	PVC
Dimensions / length	To be confirmed
Magnetic detection04
Status indicator	Red LED
Installation	Pneumatic cylinder; confirm profile and mounting compatibility.
